Four Side Seal Tap(Valve) Bag Making Machine

Automatic Four Side Sealing Plastic Bag in Box Bag Making Machine

Automatic Four Side Sealing Plastic Bag in Box Bag Making Machine

Full automatic  BIB bag (pouch) making machine is to use Plastic composite film such as BOPP, COPP, PET, PVC, nylon, multi-layer co-extruded film,aluminized composite film, paper-plastic composite film, pure aluminum foil composite film to produce bag in box .

  • Item NO.:

    HSHZD-1300C
  • Lead Time:

    40 working days
  • Product Orgin:

    China
  • Shipping Port:

    China
  • Payment:

    FOB
  • Color:

    silvery white
Product Details

Bag Making Machine for Bag-in-Box Bag and Beverage bag


Bag in Box BIB Bag Making Machine ApplicationHSHZD-1300C four side sealing and six layers unwinding valved bag machine is widely used to produce bag in box for wine, fruit juice, spring water and others to ensure the good safety and make transportation convenient. Bag in box made in our machine has advantages in tightness and flexibility to protect goods well.


Boxed Wine Bag Making Machine Electrical Equipment Configuration



Name

Description

Qty.

HMI

iP8102iQ 10.4 inch Taiwan Weinview touch screen

1set



Control system

FP-XH C60T Japan Panasonic PLC programmer

1set



Sliding Knife Motor

MSME082 (AC200V) 750W low inertia

Panasonic servo motor

1set

Fixed length traction

MDMF202L1G6M2.0KW Japan Panasonic

servo motor

(including driver)

3set

Conveying motor

61K120RGU-6GU-10K gear reducer motor

(including governor)

1set

Host Control

4KW Japan Panasonic servo motor +

precision reducer (including driver)

1set

Valve nozzle conveying

51K120RGU-5GU-10K gear reducer motor

(including speed-regulator)

2set

Hole Cutting Motor

5I60GU-Optical axis motor 12 (including

Speed regulator)

2set

Patch Motor

MSME082 (AC200V) 750W low inertia

Panasonic servo motor

1set

Unwinding Motor

CV28-0.75KW-10S TaiwanCHENBANGthree-phasegeared motor

(including frequency converter)

4set

Correction Motor

90typecorrection actuator

(including BF1500S correction controller)

6set

Unwinding Tension

25Nm magnetic powder brake

(including Automatic tension controller)

6set

Temperature Control

20 channels of temperature control, 3 sets of independenttemperaturecontrol

modules

3set

Main Control cabinet

Rocker style control cabinet

1set

Aluminium Foil 220 l BIB Bag in Box Making Machine Technical Parameters

Model

HSHZD-1300C

Function

Four-side-seal bag-in-box making machine

Suitable  material

plastic laminated film such as BOPP, COPP, PET, PVC and nylon, as well as multi layerco-extrusion film, aluminum laminated film, paper plastic laminated film, pure aluminum foil laminated film,PE/VMPET/PE

Max Speed

30 pcs/ min (affected by pouch-making length and type)

Max linear speed of unwinding

≤30m/min(range by pouch-making length and type)

Max roll dia

¢750*1300 (diameter * width)

Pouch-making dimension

Length:640mm, N=1,2,3,4,5,6(multiple material feeding)

Width:1260mm

Bag min length:180mm

Can do max 220L BIB

Positioning accuracy

≤±0.3mm

Numbers of hot knives and cooling knives

28

Numbers of temperature control lines

20 lines

Temperature set range

Room temperature-400℃

Total power

70kw

Air supply

40L/min

Cooling water

10L/min

Machine color

black

Controlling system

High speed bag making machine controlling system

Overall dimension

18800*3000*2200mm

Weight

10000kg

 BIB Boxed Wine Bag Making Machine Production Process



 Optional Equipment (not included in quotation)

1. Adding punch

If you want an extra group of punch different from punch devices of basic configuration, please inform us in advance

2. Irregular sealing cutter

Customized by client’s requirements

3. Air compressor

Clients purchase it according to requirements



Packing

Plain & moisture proof packaging



Random accessories

No

Name

Specification

Unit

Quantity

Note

1

Slotted screwdriver

6”

pc

1



2

Phillips screwdriver

6”

pc

1



3

Allen key



set

1



4

Adjustable wrench

10”

pc

1



5

Oil can



pc

1



6

Cutter



pc

1



7

Silica gel cap

10

pc

4



8

Thermocouple wire

Type E

pc

2



9

Winding machine

Type 500

set

2



10

Technical document



set

1



Knowledge

How to fill liquid to liquid bag?

Bag in Box Making Machine Working Video



High End BIB (Bag in Box) Making Machine

 Why choose us?

●16 years focus on pouch making machine!Our expericnec is your advantage!

●Direct manufacturer(own factory)!

●Pouch making machine get Japan Panasonic and European engineer’s praise!

●480 set machine installed!

●2 years warranty time!

●Origin Idea ,design by our own engineer,accept OEM or ODM!

●Highed skilled engineer ,easy operation!

●Turn-key project, remote support on line!

●Photos and videos can be taken while testing the machine, so that you can check the specifications and quality on line!

●Qualified machine under global safety standards to guarantee production safety and workers security.


Get Free Inquiry Now

We will contact you as soon as possible!

Related Products
automatic vacuum bag making machine
Automatic vacuum compression storage bag making machine

Full Automatic  vacuum compression storage bag (space save vacuum sealed storage bag) machine is used to  produce vacuum compression  bag  with high production speed.

Bag-In-Box Bag Making Machine
BIB Bag-In-Box Making Machine

High end BIB (Beverage Bag in Box )Making Machine is  a new developed bag making machine in 2019. It adopts Euro hot sealing technology  and it is suitable for all the hot sealing material. It can save 51% power than common type HSHZD-1300C BIB making machine. Warranty time: 2 years. More and more repeat orders from big group listed company comes!

Air Column Cushion Packaging Bags  Roll Making Machine
Air column cushion packaging bags roll making machine

This is air column bag making machine It is a special equipment for producing various air column bags and air cushions withstand a weight of 60 to 120 kilograms without breaking, and it is an environmentally friendly product. This kind of packaging is widely used in various fields, such as red wine bottles, toner cartridges, household appliances, logistics, etc.

 IBC Liner  Machine/ Container Bag/ Moisture-Proof and Leak Proof Inner Bag Making Machine
IBC liner machine/ container bag/ moisture-proof and leak proof lnner bag making machine

IBC Liner bag making machine is suitable for Pure PE, Alu foil and all the other hot sealing material! It adopts European hot sealing technology to reach a perfect sealing effect!

High End Plastic Customised Vacuum Compressed Frosted Zipper Bag Making Machines For Clothing Storage
High End Plastic Customised Vacuum compressed frosted zipper bag making machines for clothing storage

Automatic high speed vacuum compressed bag making machine  is suitable for all the hot sealing material,such as  LDPE, PA  co- extrusion film, Composite film, Degradable film etc.

High Quality Full Automatic Bag Making Machine Price BIB Eco Bags Making Machine For Making plastic Bag
High quality full automatic bag making machine price BIB eco bags making machine for making plastic bag

This is automatic high speed bag in box(BIB) making machine ,Suitable for all the hot sealing material , such as pure PE LDPE, PA  co- extrusion film, Composite film, Degradable film etc.
