PP Woven Bag Making Machine

Roll to Roll Printing Machine

Roll to Roll Printing Machine

This is roll to roll printing machine, the color number you needed can  be customized. Roll-to-roll printing is an industrial printing process used for materials such as vinyl and paper. This is a very efficient technology because it can print large prints and can be rolled up and shipped quickly. The roll-to-roll method uses continuous pieces of material throughout the process (from start to finish).

Product Details

                                                            PP Woven Bag Roll to Roll Printing Machine


Parameter

Max Feeding Width

800mm

Max Printing Width

700mm

Printing Plate Perimeter

1271 mm

(Only full versions with a bag length of 1200mm can be printed, full versions with other lengths cannot be printed; if the bag length is within 1200mm, a 100mm blank space must be reserved for printing. The bag length is between 1200mm and 1400mm, and the length of the printing surface cannot exceed 1000mm)

Winder &Unwinder Dia

≤1300mm

Plate Thickness

4-5mm

Printing Speed

120m/min

Registering Tolerance

±0.5mm

Single Group

 Printing Unit Power

Servo motor drive separately (1.5w)

Traction before and after printing

Front 3KW,back 3KW

Servo motor drive separately

Drying

Each color with one double wind oven box

Registering

 Vertical electric registering

Total Power

17KW



Drying Box Power

16KW



Machine SizeL X W

131.85m(not include ELECTRIC BOX



Machine size

153.5m



Printing Color

4+0,3+1,2+2



Printing machine frame

Steel Plate




Why choose us?

16 years focus on pouch making machine !Our experience is your advantage!
Direct factory!
Pouch making machine get European engineer’s praise!
480 set machine installed!
Origin Idea ,design by our own engineer , accept OEM or ODM!
High skilled engineer ,easy operation!
Turn-key project, remote support on line!
Qualified machine under global safety standards to guarantee production safety and workers security.
